High-Performance Lasers for Advanced LiDAR Applications
Sivers Photonics is at the forefront of LiDAR technology, delivering high-power light sources that enable accurate distance and velocity measurements. Our high-power ridge-waveguide DFB lasers offer narrow linewidths, excellent wavelength stability, and scalability — meeting the performance demands of autonomous vehicles, robotics, and industrial sensing applications.
These lasers are designed for developers and manufacturers of LiDAR systems for autonomous vehicles, driver-assist systems, robotics, and industrial or environmental sensing.
Why Sivers for FMCW LiDAR?
High-yield ridge-waveguide and dual-ridge architectures ensure consistent wavelength control and performance.
Ultra-low FIT rates (<1) deliver the high-reliability required for safety-critical systems
and automotive qualification.
Etched-facet, on-wafer coated design allows full optical testing before dicing — reducing cost and improving reliability.
Lasers can be optimized for seamless hybrid SiPh integration.
On-wafer coating and testing eliminate bar processing, improving yield and scalability.
What Problems We Solve
Our CW DFB lasers provide precise wavelength control, narrow linewidths, and stable output for accurate distance and velocity measurements. With high optical power and robust operation in non-hermetic environments, they facilitate compact, high-resolution LiDAR modules with consistent performance across temperature and lifetime.
Key Benefits
- Upto 100mW power output with narrow linewidths for precise depth, proximity, and long-range LiDAR sensing.
- Ridge-waveguide design ensures single-mode operation, high yield, and low-cost manufacturability.
- Etched-facet, on-wafer coated & tested eliminates bar processing, reducing cost, simplifying assembly, and improving manufacturing yield.
- Ultra-low FIT rates and operation from 20 °C to 70 °C, suitable for high-volume applications
Product Portfolio
We focus on InP sources optimised for silicon photonics integration. We offer high power, InP-based DFB lasers and gain chips, as single emitters or arrays, on our InP100 Product Platform

Platform Advantages
- Wafer-level processing and testing for scalability and cost efficiency.
- Proven architecture with ultra-low FIT rates for long-term reliability.
- Flexible customization options for power, wavelength, and form factor.
- Non-hermetic compatibility lowers packaging complexity and cost.
FAQ
Yes see our product portfolio for a range of standard devices currently underqualification. We can provide you with data sheets, samples and lead times for each. Don’t see what you’re looking for? Please reach out, our team will be happy to discuss your requirements.
Absolutely. Our in-house design team can take you from initial concept through custom design, prototyping, qualification, and into high-volume manufacturing.
InP100 is our 4” Indium Phosphide processing platform – a library of qualified process modules that can be combined to build a wide range of devices. By using these proven building blocks, InP100 ensures that both established and new design concepts have the strongest chance of success from the start.
Not at this time. We provide each customer with a dedicated wafer run, giving you full flexibility to explore design options and optimize for your specific performance targets.
There’s no strict minimum. Our goal is to support you from prototyping through to high volumes. We understand every project is unique, so we’ll assess your request individually and build the right plan together.
We run a 24/7 fab and always aim to deliver as quickly as possible. Cycle time varies based on complexity and production load, but we’ll work closely with you to create a schedule that fits your needs.
